5H-21T Cross Flow Type Maize Dryer Machine 10.9kw With On Line Moisture Control (30%-12%)
Our Product Description
1, Using mix type drying method with angle pipe , hot exchange and evaporative way of drying to make sure the drying is evenly and fully;
2, Prevent drying crack broken rice we adopt constant drying speed control, water reduction rate and air temperature controlled by computer, without manual settings;
3, Prevent grain spoiled, machine running under proper temperature ;
4, Prevent excessive drying adopting automatic, accurate and safe water monitoring devices, it can be shut down automatic;
5, Body of tower is low and compact, easy to be installed;
6, High moisture rice and wheat quality also can be dried, widely used for rice, wheat, corn, soybeans and other crops;
7, Safe, reliable, easy to be cleaned;
8, A variety of fuels available, economic, environmentally friendly;
9, Easy to maintain, convenient to use;
10, Excellent quality raw materials for drying tower body, more durable.
Our Key Parameters:
Model | 5H-21 | ||
Structure | Batch type circulating | ||
Drying way | Indirect heating | ||
(t)Cyclic batch | 21 | ||
| paddy(kg) (capacity＝560kg/m3) | 5000-21000 | |
wheat(kg) (capacity＝700kg/m3) | 6000-21000 | ||
Total weight(kg) | 4300 | ||
diemension | 4180×3727×12735 | ||
| Model | 4-72-7.1A | |
rated air flow (m3/h) | 16576-8288 | ||
Burner | Model | husk burner/gas burner/Diesel burner | |
Ignition | Manual | ||
fuel consumption | 40-60 | ||
fuel | rice hull,firewood,straw,anthracite | ||
electricity | Voltage/frequence | Three phase 380V Single phase 220V/50hz | |
kW motor power | 10.9 | ||
function |
| paddy(min) | 55-70 |
wheat(min) | 50-65 | ||
| paddy(min) | 55-70 | |
wheat(min) | 50-65 | ||
capacity(Kg/h) | ≥2280 | ||
drying capacity (t.%/h) | ≥15 | ||
drying rate (%/h) | 0.5-1.2 | ||
device | safety device | Grain temperature sensor, Fault alarm, Full load buzzer,Over0temperature alarm, Thermal-over relay, Hot air temperature sensor, Overload protection device, Leakage protection device | |
standard device | Online moisture monitor, Conveying system, Unloading system, Drying system, Tempering system, Elevator, Exhaust fan in low noise, Automatic control system | ||
